Vector CANalyzer

CANalyzer is the comprehensive software tool for analyzing and stimulating network communication in the automotive industry and related fields. It allows you to verify and understand communication occurring on your network, offering capabilities for sending, recording, and interactively diagnosing ECUs. Whether you are a beginner or an experienced user, CANalyzer provides powerful basic functions and extensive detailed features tailored to your needs.

Key Advantages:

• Intuitive Operation: Easy to learn and use.
• Comprehensive Observation: Effortlessly monitor, analyze, and supplement data traffic.
• Flexible Analysis: Utilize configurable function blocks like Filters, Interactive Generators, and Replay for in-depth analysis.
• Seamless Logging & Replay: Log network data continuously and replay it for offline analysis.
• Programmable: Flexible programming with CAPL for advanced analysis tasks.

CANalyzer is available in two editions:

• Desktop Edition (DE): For applications at standard workstations.
• Test Bench Edition (TBE): For executing tests at test and production stations, enabling remote access and execution in real and virtual environments.

Highlights in Version 18:

• State Tracker: Graphical display of state changes, allowing analysis of states, state transitions, signals, and CAN messages to visualize temporal dependencies.

Application Areas:

• Analysis: Evaluate information exchange between ECUs and software functions, from physical values to symbolic signals.
• Diagnostics: Analyze ECU communication, supporting all relevant automotive networks and transport protocols with semi-automated and interactive diagnostic tests.
• Stimulation: Observe, analyze, and influence ECU data traffic by sending messages and signal values to the System Under Test (SUT) for reproducible testing and scenario extension.

Editions and Options:

• Variants: CANalyzer pro (full functionality, including CAPL) and CANalyzer exp (for standard applications, without CAPL programming).
• Options: Extend CANalyzer's capabilities with specialized functionalities for various bus systems, protocols, and measurement tasks.

Security Features:

• Security Manager: A uniform solution for analyzing security-protected ECUs and networks, supporting use cases like SecOC, Authentication, Variant Coding, TLS, and MACsec.

Explore further with product descriptions, release notes, system requirements, and available training.
